1-30T/H Small Crawler Mobile Jaw Crushing Plant

Small Crawler Jaw Crushing Plant with a fully hydraulically driven crawler vehicle chassis, which can meet the customers’ requirement of high mobility, high crushing efficiency and optimizes your business mode.

Capacity: 1-30t/h

Max Input size: <200mm

Min Output size: 10-70mm

1-30T/H Crawler Type Crushing Plant, as the independent crushing and sand making high-end small production plant, represents a cutting-edge solution for efficient and versatile material processing in the aggregate and mining industries. Designed for mobility and flexibility, this plant integrates a robust jaw crusher with a crawler-mounted undercarriage, enabling it to navigate diverse terrains and operate effectively in various environments.

Technical Feature:

1.Enhanced Mobility:

The crawler system provides superior maneuverability, allowing the plant to move easily across rough and uneven surfaces. This is particularly beneficial for working in remote or challenging locations where traditional wheeled equipment might struggle.

2.High Crushing Efficiency:

Equipped with a powerful jaw crusher, the plant delivers high-performance crushing capabilities, handling a wide range of materials including hard rocks, ores, and construction debris. The jaw crusher’s design ensures optimal size reduction and superior material output.

3.Versatile Applications:

Ideal for primary crushing in both stationary and mobile operations, the crawler-type jaw crushing plant is suitable for use in quarrying, mining, and recycling applications. Its adaptability makes it an essential tool for various industries requiring reliable and efficient material processing.

4.Robust Construction:

Built to withstand demanding conditions, the plant features a durable and sturdy construction, ensuring long-term reliability and minimal maintenance requirements. Its design incorporates advanced technology for enhanced performance and reduced operational costs.

5.Ease of Operation:

With user-friendly controls and advanced automation features, the crawler-type jaw crushing plant offers simplified operation and maintenance. This ensures consistent performance and reduces the need for extensive operator intervention.

The core component of the crawler jaw crushing plant is the jaw crusher. It consists of two main jaws—one fixed and one moving (swing) jaw. The moving jaw is attached to a crank mechanism, which allows it to move back and forth in an oscillatory motion.Once the material is crushed to the required size, it is discharged through the bottom of the jaw crusher onto a conveyor belt or similar system.

One iron remover is installed upon the discharging belt to remove iron. This conveyor system transports the crushed and iron-removed material to the next stage in the processing plant or stockpiles it for further use. Meanwhile, Whole plant powering system is self-diesel generator, and user can control whole station by Electrical control cabinet.
